Chassis Dimensions and Parameters |
Overall Dimension(L x W x H) |
5900×1980×2200mm |
|
Wheelbase: |
3360mm |
|
|
Front/ Rear Wheel Distance: |
1504/1525mm |
|
|
Front/Rear Suspension |
1015/1525mm |
|
|
Approach/Departure angle: |
24/16° |
|
|
Leaf Spring: |
3/3+2 |
|
|
Weights and Capacities |
Curb Weight: |
3170kg |
|
Payload: |
4000kg |
|
|
GVW: |
7300kg |
|
|
Axle Loads: |
1805/2690kg |
|
|
Engine |
Engine Model: |
4KH1CN5HD |
|
Max output: |
95Kw |
|
|
Displacement: |
3000ml |
|
|
Horsepower: |
130Ps |
|
|
Transmission |
Transmission: |
MSB-5 |
|
Forward Gear: |
5 Speed Gear |
|
|
Backward Gear: |
1 Speed Gear |
|
|
Brake |
HydraulicBrake |
|
|
Front Drum Back Drum |
||
|
Without Exhaust Brake |
||
|
Generator |
12V- 60A |
|
|
Cab |
Number of Seats: |
2 |
|
Chassis |
Drive Type: |
4x2 |
|
Tires: |
7(Including Spare Tire) |
|
|
Tire Model: |
7.00R16 8PR |
|
|
Fuel Tank |
Number: |
1 |
|
Capacity: |
100L |
|
|
Top Parameters |
Water Tank Volume |
3200L |
